ZEUS-86

Roku’s most powerful and largest high accuracy machine. Includes twin ball screws, HSK-E50 / 25,000 RPM Spindle.

When you start your search for a milling machine, there are a few things that every machine—regardless of size, make, or brand—should be able to accomplish. High speed, high precision, the ability to perform ultra-fine machining at the micro and macro levels, and much more.

The ZEUS-86 does all that, and more.  With internal cooling capabilities specifically designed to enable high-speed milling while minimizing deformations, production errors, or downtime, the ZEUS-86 delivers everything your shop floor needs in a high-performance milling machine. It can do all of this—while handling a workpiece up to 1,763 lbs. in weight.  The high-rigidity bed with ideal rib distribution guarantees static positioning accuracy of ±0.000080″ and ±0.000030″ repeatability.  The ZEUS-86 is capable of a wide spindle speed range (200 – 25,000 RPM) using an oil-mist lubricated spindle and a 20-HP AC spindle motor.

The ZEUS-86 is a unique member of the Roku machine family as it uses a Twin Drive System for the Y-axis.  This is a twin direct drive motor/ball screw system that is designed to move the large table and workpiece weight and still maintain its high degree of accuracy.

From productivity to profit margins, this is one big machine that’s ready to make a big impact on your business.

RIGID CONSTRUCTION FOR UNYIELDING ACCURACY

  • The ZEUS-86 has been designed using a high-rigidity base casting, a twin drive Y-axis ball screw system moving the table and workpiece weight, and a dual Z-axis balance cylinder that all work together to provide smooth, precise, and stable movement. That’s quite a mouthful, but the results are simple: reliable, error-free milling you can count on, no matter what.

OPTIMIZE YOUR FLOOR PLAN WITH “HYBRID” MACHINING

  • The ZEUS-86 is built to handle big jobs, but it’s also big on multifunctionality. By offering multiple milling capabilities all in one single machine, this machine brings maximum utility to your floor plan in an economical way, allowing you to save on space without cutting back on performance.

FINE WORK AT ANY SKILL LEVEL

  • Coupled with the Fanuc 31i-B5 CNC controller, the ZEUS-86 is an exceptionally well-built machine tool that can be operated by users of nearly any skill level. Operators can produce great results with unsurpassed speed and accuracy—even for the most complex, demanding, or difficult projects.

CAPABILITIES:

  • The ZEUS-86’s high-rigidity, bridge-type monoblock structure allows high-speed, high-precision machining, while the minimized distance between the Z-axis guideways and spindle center provides greater stability
  • The high-rigidity bed with ideal rib distribution guarantees static positioning accuracy of ±0.000080″ and ±0.000030″ repeatability
  • The ZEUS-86 is capable of a wide spindle speed range (200-25,000 RPM) using an oil-mist lubricated spindle and a 20-HP AC spindle motor
  • High-speed direct hard milling is possible via dry or semi-dry oil-mist systems
  • New HSK-E50 holder achieves 6 times higher clamping force than a regular BT shank while dual balance cylinders reduce the load for the Z-axis ball screw and servo motor
  • The ZEUS-86 is a unique member of the Roku-Roku machine family as it uses a twin drive system for the Y-axis. This is a twin direct drive motor/ball screw system that is designed to move the large table and workpiece weight and still maintain its high degree of accuracy
  • The ZEUS-86 features a Fanuc 31i-B5 super high-speed processor and Al Contour Control II – A “NANO CNC system” with intelligent velocity control, NANO interpolation, and NANO smoothing
  • The entire machine is designed using HIS (Heat Isolation System) that combines heat discharge fans on all axes and dual chiller systems to cool the spindle and machining coolant. Thermal growth control is held to ±0.1°C using this combined system.



COMPONENTS:

  • High-rigidity structure for greater stability and accuracy in flood machining and hard milling
  • High-horsepower machining using an oil-mist lubricated spindle and a 20-HP AC spindle motor
  • Extended speed range – 200 through 25,000 RPM
  • High-rigidity HSK-E50 tool holders, allowing 6x higher clamping force than a regular BT shank for highly reliable work
  • 30-Position automatic tool changer
  • Roller pack-type linear motion ways
  • Twin drive ball screw Y-axis
  • Dual Z-axis balance cylinder
  • Z- and Y-axis thermal compensation
  • Blum laser tool measurement system, standard
  • 62.5-gallon coolant tank standard
  • X, Y, Z axis linear scales
  • Spindle chiller with 7-gallon oil tank

USER INTERFACE:

  • Fanuc 31i-B5 super high-speed processor with AI Contour Control II and NANO interpolation

ADDITIONAL BENEFITS:

  • remote360°-enabled (remote user monitoring, diagnostics, service support, and more)
Machine Travels: X x Y x Z in (mm) 31.5 x 23.6 x 15.7 (800x 600 x 400)
Spindle Speed 200 ~ 25,000 RPM
Spindle HP (kW) 20 (15)
Spindle Lubrication Oil Mist
Tool Changer Size 30 Position Standard(60 Tools Optional)
Positioning Accuracy/Repeatability: in (μm) ±0.000080/±0.000030(±2.0/±0.8)
Table Work Area X x Y: in (mm) 37.4 x 23.6 (950 x 600)
Table to Spindle Nose Distance: in (mm) 7.8 ~ 23.6 (200 ~600)
Max. Workpiece Weight: lb (kg) 1,763 (800)
Coolant Tank Capacity: gal (L) 62.5 (237)
Table Height from Floor: in (mm) 37.4 (950)
Actual Measured Circularity (2.0″ dia.@8 IPM): in (μm) 0.000078 (2.0)
Spindle Taper HSK-E50
Spindle Air Purge Standard
Air Blast through Spindle Standard
Oil Mist with Collector Optional
Linear Scales X, Y, Z – axes Heidenhain 0.00001mmStandard
Rapid Traverse Speed: in/min. (m/min.) 787 (20)
Cutting Speed (Normal Mode): in/min.(mm/min.) 0.01 – 315 (0.25 ~8000)
Cutting Speed (GR Super PC Mode): in/min. (m/min.) 590 (15)
Dust Collection System NA
Machine Weight: lb (kg) 17,640 (8000)
Machine Height: in (mm) 129 (3276)
Required Floor Space [Machine Unit]: in (mm) 110.2 x 153.5 (2800 x3900) includes rear clearance
Control Unit Fanuc 31i-B5 Super High-SpeedProcessor and Al Contour Control II
Power Requirements KVA 200 ~ 220V 32.5KVA
Air Supply 17.5 cu.ft./min @ 72psi
