MV2400-S Advance Type M800 Wire EDM
A cost-effective solution for medium to large size applications – combines machine performance and versatility.
The MV2400-S Advance Type M800 is part of the most innovative and user-friendly wire EDM machine series on the market. The MV2400-S features our continued dedication to high precision and innovative technology with the highly reliable non-contact cylindrical drive system on the X and Y axis drives.
With advancements in machine construction and power supply technology, the MV2400-S is sure to revolutionize EDM machining and increase your shop’s productivity.
INCREASED UTILITY
- The MV2400-S delivers the same durability, utility, and top-quality results you expect from the MV-S series, with larger internal geometries for larger projects.
HIGHLY COST-EFFECTIVE
- Lower material consumption, power requirements, and non-contact internal mechanisms keep operating costs low across the board.
- This machine comes with the M800 series control, granting you and your team easy access to a wealth of useful data and hidden insights. The 19-inch touchscreen enables the user to swipe, pinch, and tap to view, making it an easy way to increase productivity and help keep track of production jobs.
INSIGHTFUL, EASY-TO-USE CNC CONTROL
This machine comes with the M800 series control, granting you and your team easy access to a wealth of useful data and hidden insights. The 19-inch touchscreen enables the user to swipe, pinch, and tap to view, making it an easy way to increase productivity and help keep track of production jobs.
CAPABILITIES:
- Fully fiber optic servo control allows 4x faster internal communication speeds
- Submerged machining to 12.2” deep
- DMX-S (Digital Matrix Sensor) shapes each spark, reducing electrode wear
- New 17” auto-threading annealing length improves threading reliability
COMPONENTS:
- V350-V AEII power supply with digital spark control
- Non-contact, zero-backlash linear shaft drive system (X, Y axis)
- 3-piece, hardened, 3-sided stainless worktable
- Fine-grain “Dianite” casting material
- Fixed table traveling column construction (column moves in X, Y axis)
- Full-time AEII (anti-electrolysis) power supply protection
- Dielectric fluid chiller standard
- DC-servo (closed loop) torque-control wire-tensioning system
- Linear motion guideways
- All-axes absolute control system
- Linear glass scale feedback (X, Y axis)
- Optical rotary encoder feedback (U, V, Z axis)
OPTIONAL COMPONENTS:
- Scrap wire processor (chopper)
ON-BOARD AUTOMATION:
- Automatic fluid level control
- Automatic vertical machine tank door
- Auto-oiler lubrication system
- Fully automatic rough machining control covers PM, CM-R, and EM functions
USER INTERFACE:
- M800 series CNC control with 19” ergonomic touchscreen
- Program input methods:
- Keyboard
- USB flash memory
- Ethernet with FTP standard
SYSTEM INFORMATION:
- Windows 8-embedded operating system
- CFAST compact flash card memory with 1GB user program storage
- Inverter-controlled 16-step programmable flushing
ADDITIONAL BENEFITS:
- Full 2-year warranty with Triple Diamond Partnership Program
- Cylindrical drive system is covered by a special 10-year positioning warranty
- remote360-enabled (remote user monitoring, diagnostics, service support, and more)
- Comes with one complimentary preventative maintenance visit—to be used by the end of 1styear
| Machine Travels: X x Y x Z in (mm) | 23.6 x 15.7 x 12.2 (600 x 400 x 310) |
|---|---|
| Maximum Workpiece Dimensions: W x D x H in (mm) | 41.3 x 32.3 x 12.0 (1050 x 820 x 305) |
| Max. Submerged Workpiece Weight: lb (kg) | 3307 (1500) |
| Table Dimensions: in (mm) | 33.0 x 22.0 (840 x 560) |
| U/V Travels (from center): in (mm) | ±3.0 x ±3.0 (±75 x ±75) |
| Taper Angle @ Thickness: in (mm) | 15 deg.@ 10.2 (15 deg.@ 260) |
| Wide Angle Taper (Optional Guides Required) | 45 deg. @ 2.4″ 60mm (No AT Possible) |
| Table Rapid Feed Speed: in/min (mm/min) | 51.2 (1300) |
| Power Supply | V350-V |
| Minimum Drive Unit / Resolution | 0.000002 / 2 µin ( 0.00005 / 50nm) |
| User Program Storage [Hard Disk Size] | 1 GB [32 GB CFAST Card Size] |
| Wire Diameter Possible: in (mm) | 0.004~0.012 (0.1~0.3) |
| Minimum Start Hole Diameter: in (mm) | 0.02 (0.5) |
| Max. Wire Spool size On Machine / Cabinet STD: lb (kg) | 22 / 44 (10 / 20) |
| Filters / Type | 2 / Paper |
| Filter Tank Capacity: gal (L) | 227 (860) |
| Machine System Dimensions: in (mm) | 105.8 x 119.3 (2687 x 3030) |
| Machine Installed Height: in (mm) | 84.6 (2150) |
| Machine System Weight: lb (kg) | 7716 (3500) |
| Fluid System Weight: lb (kg) | 711 (350) |
| Power Requirements [KVA] | 200-230V [13.5] Built in AVR |
| Compressed Air Requirements | 2.7 cu.ft./min. @ 71~100 psi |
